Variants Axioscope 7 You can customize this list by removing one or more columns. Show all variants (5) Show all Hide all	Microscope Axioscope 7 LED for transmitted light brightfield Item no.: 490040-0058-000	Microscope Axioscope 7 RL BF/DF Item no.: 490042-0001-000	Microscope Axioscope 7 RL BF/DF/C-DIC, TL Item no.: 490042-0002-000	Microscope Axioscope 7 LED for epi-fluorescence B/G Item no.: 490040-0059-000	Microscope Axioscope 7 complete system Item no.: 490040-0054-000

Variants Axioscope 7 You can customize this list by removing one or more columns. Show all variants (5) Show all Hide all	example picture Microscope Axioscope 7 LED for transmitted light brightfield Item no.: 490040-0058-000 Microscope Axioscope 7 LED for transmitted light brightfield Item no.: 490040-0058-000 Microscope Axioscope 7 LED for transmitted light brightfield with objectives EC Plan-Neofluar Microscope Axioscope 7 LED for transmitted light brightfield...	example picture Microscope Axioscope 7 RL BF/DF Item no.: 490042-0001-000 Microscope Axioscope 7 RL BF/DF Item no.: 490042-0001-000 Microscope Axioscope 7 RL BF/DF LED for reflected-light bright field and dark field, with phototube Microscope Axioscope 7 RL BF/DF LED for reflected-light brig...	example picture Microscope Axioscope 7 RL BF/DF/C-DIC, TL Item no.: 490042-0002-000 Microscope Axioscope 7 RL BF/DF/C-DIC, TL Item no.: 490042-0002-000 Microscope Axioscope 7 RL BF/DF/C-DIC, TL LED for reflected-light bright field, dark field and C-DIC, with LED transmitted light and phototube Microscope Axioscope 7 RL BF/DF/C-DIC, TL LED for reflected-...	example picture Microscope Axioscope 7 LED for epi-fluorescence B/G Item no.: 490040-0059-000 Microscope Axioscope 7 LED for epi-fluorescence B/G Item no.: 490040-0059-000 Microscope Axioscope 7 LED for epi-fluorescence B/G with LED transmitted light and objectives EC Plan-Neofluar Microscope Axioscope 7 LED for epi-fluorescence B/G with LED...	example picture Microscope Axioscope 7 complete system Item no.: 490040-0054-000 Microscope Axioscope 7 complete system Item no.: 490040-0054-000 Microscope Axioscope 7 TCA for technical cleanliness analysis, particle size >= 50 µm. Technical Cleanliness Analysis (TCA) is a standard based application with technical minimum requirements regarding the microscope, digital camera and PC hardware. Modifications are only possible after consultation with the support. Including bright field, polarization, objectives EC Epiplan- Neofluar 2.5x/5x, camera, stand, scanning stage, dust cover, workstation, monitor, ZEN core and modules for Technical Cleanliness Analysis. Microscope Axioscope 7 TCA for technical cleanliness analysi...
Microscope stands upright	Microscope stands upright Microscope stand Axioscope 7, TL MOT, 6x H DIC encoded Microscope stand Axioscope 7, TL MOT, 6x H DIC encoded Item no.: 430035-9310-000 Microscope stand Axioscope 7, TL MOT, 6x H DIC encoded - lower stand part with dovetail illumination interface - transmitted-light illumination with white LED 10W, optional for HAL 100W - dovetail mount for attachable stage carriers - motorized parfocality function - 24 mm motorized focus lift (min. step width 78 nm), adjustable focus stop - 6-position filter wheel for dia. 36 mm filters in TL - mount for 2-position filter slider 14x40, d=36 mm - integrated 24V DC 100W power unit, stabilized 100...240V AC/ 50...60Hz - country-specific power cable - ECO mode and light management control button - Snap button supports ZEISS Axiocam - USB 2.0 to PC - CAN interface for motorized stage - dust cover - filter holder in TL - upper stand part for transmitted light with nosepiece 6x brightfield DIC, M27, encoded Item no.: 430035-9310-000	Microscope stands upright Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded Item no.: 430035-9330-000 Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded - lower stand part with dovetail illumination interface - transmitted-light illumination with white LED 10W, optional for HAL 12V 100W - dovetail mount for attachable stage carriers - 24 mm motorized focus lift (min. step width 78 nm), adjustable focus stop - 6-position filter wheel for dia. 36 mm filters - mount for 2-position filter slider 14x40, d=36 mm - CAN port for Colibri/HXP - integrated 24V DC 90W power unit, stabilized 100...240V AC/ 50...60Hz - country-specific power cable - ECO mode and light management control button - Snap button on right side supports on ZEISS Axiocam - Motion button on left side for motorized stage movement - USB 2.0 to PC - CAN interface for motorized stage - dust cover - filter holder in TL - upper stand part with dovetail interface for reflected illumination HAL 100 /HBO /HXP/Colibri - brightfield/darkfield reflected light illuminator LED 10W white - nosepiece 6x brightfield/darkfield DIC, M27, encoded - dovetail mount for encoded changeable reflector turrets and reflector Slider - built in illumination adapter, achromatic - built in luminous-field diaphragm slider - built in aperture stop slider - mount for filter slider A 14x40 mm d=25mm - mount for polarizer slider A 6x30 mm Item no.: 430035-9330-000	Microscope stands upright Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded Item no.: 430035-9330-000 Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded - lower stand part with dovetail illumination interface - transmitted-light illumination with white LED 10W, optional for HAL 12V 100W - dovetail mount for attachable stage carriers - 24 mm motorized focus lift (min. step width 78 nm), adjustable focus stop - 6-position filter wheel for dia. 36 mm filters - mount for 2-position filter slider 14x40, d=36 mm - CAN port for Colibri/HXP - integrated 24V DC 90W power unit, stabilized 100...240V AC/ 50...60Hz - country-specific power cable - ECO mode and light management control button - Snap button on right side supports on ZEISS Axiocam - Motion button on left side for motorized stage movement - USB 2.0 to PC - CAN interface for motorized stage - dust cover - filter holder in TL - upper stand part with dovetail interface for reflected illumination HAL 100 /HBO /HXP/Colibri - brightfield/darkfield reflected light illuminator LED 10W white - nosepiece 6x brightfield/darkfield DIC, M27, encoded - dovetail mount for encoded changeable reflector turrets and reflector Slider - built in illumination adapter, achromatic - built in luminous-field diaphragm slider - built in aperture stop slider - mount for filter slider A 14x40 mm d=25mm - mount for polarizer slider A 6x30 mm Item no.: 430035-9330-000	Microscope stands upright Microscope stand Axioscope 7, TL/FL MOT, 6x H DIC encoded Microscope stand Axioscope 7, TL/FL MOT, 6x H DIC encoded Item no.: 430035-9320-000 Microscope stand Axioscope 7, TL/FL MOT, 6x H DIC encoded - lower stand part with dovetail illumination interface - transmitted-light illumination with white LED 10W, optional for HAL 100W - dovetail mount for attachable stage carriers - motorized parfocality function - 24 mm motorized focus lift (min. step width 78 nm), adjustable focus stop - auto mechanical safety shutter - 6-position filter wheel for dia. 36 mm filters - mount for 2-position filter slider 14x40, d=36 mm - CAN port for Colibri/HXP - integrated 24V DC 100W power unit, stabilized 100...240V AC/ 50...60Hz - country-specific power cable - ECO mode and light management control button - snap button supports on ZEISS Axiocam - USB 2.0 to PC - CAN interface for motorized stage - dust cover - filter holder in TL - upper stand part with dovetail interface for reflected illumination HAL 100 /HBO /HXP /Colibr i - nosepiece 6x brightfield DIC, M27, encoded - dovetail mount for encoded changeable reflector turrets and reflector slider - built in illumination adapter, achromatic - mount for luminous-field diaphragm slider - mount for aperture stop slider or FL attenuator - mount for adjusting aid for HBO/XBO - mount for filter slider R, 14x40 mm d=25mm - mount for polarizer slider A 6x30 mm Item no.: 430035-9320-000	Microscope stands upright Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded Item no.: 430035-9330-000 Microscope stand Axioscope 7, TL/RL MAT MOT, 6x HD DIC encoded - lower stand part with dovetail illumination interface - transmitted-light illumination with white LED 10W, optional for HAL 12V 100W - dovetail mount for attachable stage carriers - 24 mm motorized focus lift (min. step width 78 nm), adjustable focus stop - 6-position filter wheel for dia. 36 mm filters - mount for 2-position filter slider 14x40, d=36 mm - CAN port for Colibri/HXP - integrated 24V DC 90W power unit, stabilized 100...240V AC/ 50...60Hz - country-specific power cable - ECO mode and light management control button - Snap button on right side supports on ZEISS Axiocam - Motion button on left side for motorized stage movement - USB 2.0 to PC - CAN interface for motorized stage - dust cover - filter holder in TL - upper stand part with dovetail interface for reflected illumination HAL 100 /HBO /HXP/Colibri - brightfield/darkfield reflected light illuminator LED 10W white - nosepiece 6x brightfield/darkfield DIC, M27, encoded - dovetail mount for encoded changeable reflector turrets and reflector Slider - built in illumination adapter, achromatic - built in luminous-field diaphragm slider - built in aperture stop slider - mount for filter slider A 14x40 mm d=25mm - mount for polarizer slider A 6x30 mm Item no.: 430035-9330-000
Stand accessories	Stand accessories Stage carrier D/A; attachable and vertically adjustable Stage carrier D/A; attachable and vertically adjustable Item no.: 430710-9001-000 Stage carrier D/A; attachable and vertically adjustable for Axioscope, to accommodate screw-on stages Item no.: 430710-9001-000 Condenser carrier with vertical adjustment on both sides Condenser carrier with vertical adjustment on both sides Item no.: 430720-9001-000 Condenser carrier with vertical adjustment on both sides for use with attachable Axio Scope stage carriers, adjustable height stop Item no.: 430720-9001-000	Stand accessories Stage carrier D/A; attachable and vertically adjustable Stage carrier D/A; attachable and vertically adjustable Item no.: 430710-9001-000 Stage carrier D/A; attachable and vertically adjustable for Axioscope, to accommodate screw-on stages Item no.: 430710-9001-000 Reflector turret 4x encoded, changeable, for P&C modules Reflector turret 4x encoded, changeable, for P&C modules Item no.: 424940-9061-000 Reflector turret 4x encoded, changeable, for P & C modules Item no.: 424940-9061-000	Stand accessories Stage carrier D/A; attachable and vertically adjustable Stage carrier D/A; attachable and vertically adjustable Item no.: 430710-9001-000 Stage carrier D/A; attachable and vertically adjustable for Axioscope, to accommodate screw-on stages Item no.: 430710-9001-000 Condenser carrier with vertical adjustment on both sides Condenser carrier with vertical adjustment on both sides Item no.: 430720-9001-000 Condenser carrier with vertical adjustment on both sides for use with attachable Axio Scope stage carriers, adjustable height stop Item no.: 430720-9001-000 Reflector turret 4x encoded, changeable, for P&C modules Reflector turret 4x encoded, changeable, for P&C modules Item no.: 424940-9061-000 Reflector turret 4x encoded, changeable, for P & C modules Item no.: 424940-9061-000	Stand accessories Stage carrier D/A; attachable and vertically adjustable Stage carrier D/A; attachable and vertically adjustable Item no.: 430710-9001-000 Stage carrier D/A; attachable and vertically adjustable for Axioscope, to accommodate screw-on stages Item no.: 430710-9001-000 Condenser carrier with vertical adjustment on both sides Condenser carrier with vertical adjustment on both sides Item no.: 430720-9001-000 Condenser carrier with vertical adjustment on both sides for use with attachable Axio Scope stage carriers, adjustable height stop Item no.: 430720-9001-000 Reflector turret 4x encoded, changeable, for P&C modules Reflector turret 4x encoded, changeable, for P&C modules Item no.: 424940-9061-000 Reflector turret 4x encoded, changeable, for P & C modules Item no.: 424940-9061-000	Stand accessories Stage carrier D/A; attachable and vertically adjustable Stage carrier D/A; attachable and vertically adjustable Item no.: 430710-9001-000 Stage carrier D/A; attachable and vertically adjustable for Axioscope, to accommodate screw-on stages Item no.: 430710-9001-000 Reflector turret 4x encoded, changeable, for P&C modules Reflector turret 4x encoded, changeable, for P&C modules Item no.: 424940-9061-000 Reflector turret 4x encoded, changeable, for P & C modules Item no.: 424940-9061-000
Stages and accessories	Stages and accessories Mechanical stage 75x50 R with hardcoat anodized surface Mechanical stage 75x50 R with hardcoat anodized surface Item no.: 432035-9004-000 Mechanical stage 75x50 R with hardcoat anodized surface - 220 x 150 mm stage plate - rackless X-guide positioned at bottom, hidden gear in Y-guide - right drive 135 mm (extendable by 15 mm), with friction setting Item no.: 432035-9004-000 Specimen holder for two slides 76x26mm, spring lever left Specimen holder for two slides 76x26mm, spring lever left Item no.: 432333-9002-000 Specimen holder for two slides 76x26mm, spring lever left Item no.: 432333-9002-000	Stages and accessories Mounting frame for two slides 76x26 (D) Mounting frame for two slides 76x26 (D) Item no.: 432318-9000-000 Mounting frame for two slides 76x26 (D) - frame size 160x116 Item no.: 432318-9000-000 Metal Insert Plate (D) Metal Insert Plate (D) Item no.: 432313-0000-000 Metal Insert Plate (D) plane plate, horizontally fine adjustable - frame size 160x116 - with grid lines Item no.: 432313-0000-000 Mechanical stage 80x60 mot standard; CAN (D) Mechanical stage 80x60 mot standard; CAN (D) Item no.: 432039-9200-000 Mechanical stage 80x60 mot standard; CAN (D) for Axioscope 7 -Travel range: 80mm x 60mm - Max. velocity: 25mm/s - Smallest movement: 0.5um - Repeatability : # ±3um (bi-directional, measured according to ISO 230.2) - Accuracy (full range): # ±10um (measured according to ISO 230.2) - Max. payload: 1Kg Item no.: 432039-9200-000	Stages and accessories Mounting frame for two slides 76x26 (D) Mounting frame for two slides 76x26 (D) Item no.: 432318-9000-000 Mounting frame for two slides 76x26 (D) - frame size 160x116 Item no.: 432318-9000-000 Metal Insert Plate (D) Metal Insert Plate (D) Item no.: 432313-0000-000 Metal Insert Plate (D) plane plate, horizontally fine adjustable - frame size 160x116 - with grid lines Item no.: 432313-0000-000 Mechanical stage 80x60 mot standard; CAN (D) Mechanical stage 80x60 mot standard; CAN (D) Item no.: 432039-9200-000 Mechanical stage 80x60 mot standard; CAN (D) for Axioscope 7 -Travel range: 80mm x 60mm - Max. velocity: 25mm/s - Smallest movement: 0.5um - Repeatability : # ±3um (bi-directional, measured according to ISO 230.2) - Accuracy (full range): # ±10um (measured according to ISO 230.2) - Max. payload: 1Kg Item no.: 432039-9200-000	Stages and accessories Mechanical stage 75x50 R with hardcoat anodized surface Mechanical stage 75x50 R with hardcoat anodized surface Item no.: 432035-9004-000 Mechanical stage 75x50 R with hardcoat anodized surface - 220 x 150 mm stage plate - rackless X-guide positioned at bottom, hidden gear in Y-guide - right drive 135 mm (extendable by 15 mm), with friction setting Item no.: 432035-9004-000 Specimen holder for two slides 76x26mm, spring lever left Specimen holder for two slides 76x26mm, spring lever left Item no.: 432333-9002-000 Specimen holder for two slides 76x26mm, spring lever left Item no.: 432333-9002-000	Stages and accessories Holder TCA for filter membrane, DM 47 (D) Holder TCA for filter membrane, DM 47 (D) Item no.: 432320-9902-000 Holder TCA for filter membrane, DM 47 (D) Holder for filter membrane, diameter 47 mm. Accessory for analysis of particulate contamination on filter membranes. Item no.: 432320-9902-000 Mounting frame for one holder TCA (D) Mounting frame for one holder TCA (D) Item no.: 432321-9902-000 Mounting frame for one holder TCA (D) The mounting frame is accessory for technical cleanliness and applicable for: - holder TCA for filter membranes with diameter 47 mm; - holder TCA for filter membranes with diameter 50 mm; - holder TCA for the test standard. Item no.: 432321-9902-000 Mechanical stage 80x60 mot standard; CAN (D) Mechanical stage 80x60 mot standard; CAN (D) Item no.: 432039-9200-000 Mechanical stage 80x60 mot standard; CAN (D) for Axioscope 7 -Travel range: 80mm x 60mm - Max. velocity: 25mm/s - Smallest movement: 0.5um - Repeatability : # ±3um (bi-directional, measured according to ISO 230.2) - Accuracy (full range): # ±10um (measured according to ISO 230.2) - Max. payload: 1Kg Item no.: 432039-9200-000
Tubes and accessories	Tubes and accessories Binocular phototube 30°/23 (50:50), reversed image Binocular phototube 30°/23 (50:50), reversed image Item no.: 425520-9010-000 Binocular phototube 30°/23 (50:50), reversed image camera port with interface 60N Item no.: 425520-9010-000	Tubes and accessories Binocular phototube 30°/23 (50:50), reversed image Binocular phototube 30°/23 (50:50), reversed image Item no.: 425520-9010-000 Binocular phototube 30°/23 (50:50), reversed image camera port with interface 60N Item no.: 425520-9010-000	Tubes and accessories Binocular phototube 20°/23 (100:0/0:100), upright image Binocular phototube 20°/23 (100:0/0:100), upright image Item no.: 425520-9030-000 Binocular phototube 20°/23 (100:0/0:100), upright image with sliding prism, camera port with interface 60N Item no.: 425520-9030-000	Tubes and accessories Binocular phototube 30°/23 (100:0/0:100), reversed image Binocular phototube 30°/23 (100:0/0:100), reversed image Item no.: 425520-9020-000 Binocular phototube 30°/23 (100:0/0:100), reversed image with sliding prism, low-vibration prism switch. Camera port with interface 60N Item no.: 425520-9020-000	Tubes and accessories Binocular phototube 20°/23 (100:0/0:100), upright image Binocular phototube 20°/23 (100:0/0:100), upright image Item no.: 425520-9030-000 Binocular phototube 20°/23 (100:0/0:100), upright image with sliding prism, camera port with interface 60N Item no.: 425520-9030-000
Video devices	Video devices Camera Adapter 60N-C 2/3" 0.5x Camera Adapter 60N-C 2/3" 0.5x Item no.: 426112-0000-000 Camera Adapter 60N-C 2/3" 0.5x Item no.: 426112-0000-000	Video devices	Video devices	Video devices Camera Adapter 60N-C 2/3" 0.63x Camera Adapter 60N-C 2/3" 0.63x Item no.: 426113-0000-000 Camera Adapter 60N-C 2/3" 0.63x Item no.: 426113-0000-000	Video devices Camera Adapter 60N-C 2/3" 0.63x; rotating +/- 2° Camera Adapter 60N-C 2/3" 0.63x; rotating +/- 2° Item no.: 426113-9010-000 Camera Adapter 60N-C 2/3" 0.63x; rotating +/- 2° for fine adjustment of camera rotation. - adjustment range: +/- 2° - maximum weight load: 2 kg Item no.: 426113-9010-000
Eyepieces	Eyepieces Eyepiece PL 10x/23 Br. foc. Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000 Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000	Eyepieces Eyepiece PL 10x/23 Br. foc. Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000 Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000	Eyepieces Eyepiece PL 10x/23 Br. foc. Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000 Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000	Eyepieces Eyepiece PL 10x/23 Br. foc. Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000 Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000	Eyepieces Eyepiece PL 10x/23 Br. foc. Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000 Eyepiece PL 10x/23 Br. foc. Item no.: 444036-9000-000
Eyepiece accessories	Eyepiece accessories Eyepiece eyecup Eyepiece eyecup Item no.: 444801-0000-000 Eyepiece eyecup Item no.: 444801-0000-000	Eyepiece accessories Eyepiece eyecup Eyepiece eyecup Item no.: 444801-0000-000 Eyepiece eyecup Item no.: 444801-0000-000	Eyepiece accessories Eyepiece eyecup Eyepiece eyecup Item no.: 444801-0000-000 Eyepiece eyecup Item no.: 444801-0000-000	Eyepiece accessories Eyepiece eyecup Eyepiece eyecup Item no.: 444801-0000-000 Eyepiece eyecup Item no.: 444801-0000-000	Eyepiece accessories Eyepiece eyecup Eyepiece eyecup Item no.: 444801-0000-000 Eyepiece eyecup Item no.: 444801-0000-000
Transmitted-light objectives	Transmitted-light objectives Objective EC Plan-Neofluar 10x/0.3 M27 Objective EC Plan-Neofluar 10x/0.3 M27 Item no.: 420340-9901-000 Objective EC Plan-Neofluar 10x/0.3 M27 (FWD=5.2mm) Item no.: 420340-9901-000 Objective EC Plan-Neofluar 20x/0.50 M27 Objective EC Plan-Neofluar 20x/0.50 M27 Item no.: 420350-9900-000 Objective EC Plan-Neofluar 20x/0.50 M27 (FWD=2.0mm) Item no.: 420350-9900-000 Objective EC Plan-Neofluar 40x/0.75 M27 Objective EC Plan-Neofluar 40x/0.75 M27 Item no.: 420360-9900-000 Objective EC Plan-Neofluar 40x/0.75 M27 (FWD=0.71mm), incl. Cover glasses, high performance, CG=0.17mm, box with 100 pc. Item no.: 420360-9900-000	Transmitted-light objectives	Transmitted-light objectives	Transmitted-light objectives Objective EC Plan-Neofluar 2.5x/0.085 M27 Objective EC Plan-Neofluar 2.5x/0.085 M27 Item no.: 420320-9902-000 Objective EC Plan-Neofluar 2.5x/0.085 M27 (FWD=8.8mm) Item no.: 420320-9902-000 Objective EC Plan-Neofluar 10x/0.3 M27 Objective EC Plan-Neofluar 10x/0.3 M27 Item no.: 420340-9901-000 Objective EC Plan-Neofluar 10x/0.3 M27 (FWD=5.2mm) Item no.: 420340-9901-000 Objective EC Plan-Neofluar 20x/0.50 M27 Objective EC Plan-Neofluar 20x/0.50 M27 Item no.: 420350-9900-000 Objective EC Plan-Neofluar 20x/0.50 M27 (FWD=2.0mm) Item no.: 420350-9900-000 Objective EC Plan-Neofluar 40x/0.75 M27 Objective EC Plan-Neofluar 40x/0.75 M27 Item no.: 420360-9900-000 Objective EC Plan-Neofluar 40x/0.75 M27 (FWD=0.71mm), incl. Cover glasses, high performance, CG=0.17mm, box with 100 pc. Item no.: 420360-9900-000 Objective EC Plan-Neofluar 100x/1.30 Oil M27 Objective EC Plan-Neofluar 100x/1.30 Oil M27 Item no.: 420490-9900-000 Objective EC Plan-Neofluar 100x/1.30 Oil M27 (FWD=0.20mm), incl. Immersol 518 F, oiler 20ml and Cover glasses, high performance, CG=0.17mm, box with 100 pc. Item no.: 420490-9900-000	Transmitted-light objectives
Condensers	Condensers Condenser LD aplanatic 0.8 BF, WD=5.8mm Condenser LD aplanatic 0.8 BF, WD=5.8mm Item no.: 424225-9120-000 Condenser LD aplanatic 0.8 BF, WD=5.8mm - for objectives 5x-100x - compatible with low-power system for objectives 2.5x/4x - compatible with modulator disk for phase contrast Item no.: 424225-9120-000	Condensers	Condensers Condenser, achromatic-aplanatic 0.9 H Condenser, achromatic-aplanatic 0.9 H Item no.: 424225-9060-000 Condenser, achromatic-aplanatic 0.9 H with front lens which can be switched on the right and left. For objectives 1.0x-100x, WD=1.0mm Item no.: 424225-9060-000	Condensers Condenser 0.9/1.25 H Condenser 0.9/1.25 H Item no.: 424225-9001-000 Condenser 0.9/1.25 H For objectives 5x-100x, compatible with low-power system for objectives 2.5x/4x, WD=0.8mm Item no.: 424225-9001-000 Low-power system for objectives 2.5x/4x for condenser 0.9/1.25 H Low-power system for objectives 2.5x/4x for condenser 0.9/1.25 H Item no.: 424225-9050-000 Low-power system for objectives 2.5x/4x for condenser 0.9/1.25 H Item no.: 424225-9050-000	Condensers
Image processing	Image processing Microscopy Camera Axiocam 208 color Microscopy Camera Axiocam 208 color Item no.: 426570-9001-000 Microscopy Camera Axiocam 208 color Most versatile color camera for education, documentation and routine applications with standalone capability, USB3.0 and Ethernet connectivity with 64bit driver software for: ZEN (blue and core), Labscope and TWAIN plugin. Camera package contains the following accessories: - USB 3.0 hub Type-C, - USB 3.0 flash drive, Type-C and Type-A - USB 3.0 cable Type-C to Type-A - Power <(>&<)> signal cable camera to microscope stand compatible with Axiolab 5 and Axioscope 5/7/Vario - Power adapter with country-specific plug Sensor: Sony CMOS image sensor Color, Rolling Shutter Number of Pixel: 3840 (H) x 2160 (V) = 8.3MP, Ultra HD (4K) Selectable Resolution: 3840 x 2160 = Ultra HD (4K) and 1920 x 1080 = Full HD (1080p) Pixel size: 1.85 µm x 1.85 µm Effective Area: 7.1 mm x 4.0 mm, equivalent to 1/2.1" (8.1 mm diagonal) Spectral range: approx. 400 nm – 700 nm, IR filter; RGB Bayer color mask Control buttons on camera for stand-alone use: 1x Image capture 1x OSD (On Screen Display menu) 1x Camera factory reset Status-LED for camera: color coded operation status Stand-alone: Image storage format: TIFF or JPG Video stream format: mp4 Live frame rate via HDMI: 30 fps @ 4K/1080p (also with HDR) Live frame rate through software via Ethernet or USB 3.0 (depending on hardware and software configuration), Exp. Time 1 ms: H x V Frame rate 3840 x 2160 up to 15 fps (ZEN blue edition) 1920 x 1080 up to 27 fps (ZEN blue edition) 1920 x 1080 up to 30 fps (Labscope) Digitization: 24-bit (3 x 8-bit RGB) A/D conversion Integration time: 0.06 ms up to 1 s Gain: 1x - 22x Interfaces for Communication and for Power: HDMI for monitor USB 3.0 Type C for USB hub, flashdrive, Wi-Fi adapter or, PC connection Ethernet (RJ45) for LAN connection Micro-D for power and communication with dedicated stands Optical interface: C-mount Max. file size per image: .tiff up to: 24 MB (not content dependent) .jpg up to: approx.0.5 MB – 3.3 MB (content dependent) Size/Weight: approx. 135 x 97 x 54mm / 590 g Housing: blue painted aluminum and cooling fins on the top plate Registration: CE, RoHS, CSA Power supply: via Micro-D interface Power consumption: 9 W (24 V DC,0.375 A) Environmental conditions: +10°C to +40°C, max. 75% relative air humidity at 35°C, no condensation, free air circulation required, indoor use Supported Operating systems: for ZEN: Windows 10 x64 and higher for Labscope: Windows 10 x64 and higher, iOS v11 and higher, Android 9.0 and higher Supported Application Software: ZEN v3.0 (blue edition) and higher ZEN core v2.7 and higher Labscope v2.9.1 and higher (Windows)/ v2.8.3 and higher (iOS), v4.0 and higher (Android) TWAIN plugin: Software interface to control camera by 3rd party application software The camera is network-enabled and can be used with the ZEISS iOS App, Android APP and ZEISS Labscope software. The Apps are available as a free download from the Apple® App Store, Google Play Store or ZEISS Portal. Unless otherwise stated by the distributor, iPad® and WLAN router are not supplied by ZEISS. Apple®, Apple iPad® are registered trademarks of Apple Inc. Item no.: 426570-9001-000	Image processing	Image processing	Image processing Microscopy Camera Axiocam 202 mono Microscopy Camera Axiocam 202 mono Item no.: 426570-9011-000 Microscopy Camera Axiocam 202 mono Most versatile monochrome camera for education, documentation and routine applications with standalone capability, USB 3.0 and Ethernet connectivity with 64bit driver software for: ZEN (blue and core), Labscope and TWAIN plugin. Camera package contains the following accessories: - USB 3.0 hub Type-C - USB 3.0 flash drive, Type-C and Type-A - USB 3.0 cable Type-C to Type-A - Power <(>&<)> signal cable camera to microscope stand compatible with Axiolab 5 and Axioscope5/7/Vario and, - Power adapter with country-specific plug Sensor: Sony CMOS image sensor Monochrome, Global Shutter Number of Pixel: 1920 (H) x 1080 (V) = 2MP, Full HD (1080p) Selectable Resolution: 1920 x 1080 = Full HD (1080p) Pixel size: 5.86 µm x 5.86 µm Effective Area: 11.25 mm x 6.33 mm, equivalent to 1/1.23" (13 mm diagonal) Spectral range: approx. 350 nm – 850 nm, protection glass (coated) Control buttons on camera for stand-alone use: 1x Image capture 1x OSD (On Screen Display menu) 1x Camera factory reset Status-LED for camera: color coded operation status Stand-alone: Image storage format: TIFF or JPG Video stream format: mp4 Live frame rate via HDMI: 30 fps @ 1080p Live frame rate through software via Ethernet or USB 3.0 (depending on hardware and software configuration), Exp. Time 1 ms: H x V Frame rate 1920 x 1080 up to 30 fps (Labscope, ZEN) Digitization: 12-bit or 8-bit A/D conversion Integration time: 0.30 ms up to 2 s Gain: 1x - 16x Interfaces for Communication and for Power: HDMI for monitor USB 3.0 Type C for USB hub, flash drive, Wi-Fi adapter or, PC connection Ethernet (RJ45) for LAN connection Micro-D for power and communication with dedicated stands Optical interface:C-mount Max. file size per image: 12 bit .tiff: 4 MB (one channel, not content dependent) 8 bit .tiff: 2 MB (one channel, not content dependent) 8 bit .jpg: approx. 0.1 MB – 1.3 MB (content dependent) Size/Weight: approx. 135 x 97 x 54mm / 590 g Housing: blue painted aluminum and cooling fins on the top plate Registration: CE, RoHS, CSA Power supply: via Micro-D interface Power consumption: 9 W (24 V DC, 0.375 A) Environmental conditions: +10°C to +40°C, max. 75% relative air humidity at 35°C, no condensation, free air circulation required, indoor use Supported Operating Systems: for ZEN: Windows 10 x64 and higher for Labscope: Windows 10 x64 and higher, iOS 13 and higher, Android 9.0 and higher Supported Application Software: ZEN 3.0 (blue edition) or higher ZEN core v2.7 or higher Labscope v2.9.1 and higher (Windows), v3.0 and higher (iOS) , v4.0 and higher (Android) TWAIN Plugin (Software interface to control camera by 3rd party application software) The camera is network-enabled and can be used with the ZEISS iOS App, Android APP and ZEISS Labscope software. The Apps are available as a free download from the Apple® App Store, Google Play Store or ZEISS Portal. Unless otherwise stated by the distributor, iPad® and WLAN router are Not supplied by ZEISS. Apple®, Apple iPad® are registered trademarks of Apple Inc. Item no.: 426570-9011-000	Image processing Microscopy Camera Axiocam 705 pol R2 (D) Microscopy Camera Axiocam 705 pol R2 (D) Item no.: 426560-9071-000 Microscopy Camera Axiocam 705 pol R2 (D) High Performance microscopy camera incl. driver software 64 bit USB 3.0 PCIe x1 interface, USB 3.0 cable 3 m and protection glass (wideband coated) Sensor Type: SONY IMX250 MZ Exmor CMOS, SONY Pregius Global Shutter Monochrome with 2x2 pixel specific polarization filter mask (90°, 45°, 135°, 0°) Number of Pixels: 2464 (H) x 2056 (V) = 5.07 Mega pixel Pixel Size: 3.45 µm x 3.45 µm Chip Size: 8.5 mm x 7.1 mm, equivalent to 2/3" (diagonal 11.1 mm) Spectral Range: With protection glass approx. 350 nm to 1000 nm Full Well Capacity: Approx. 11,000 e at gain 1x (typ.) Adjustable Signal Amplification: 1x, 2x, 4x, 8x, 16x Selectable Resolution: H x V Binning Factor (1x1) 2464 x 2056 1x1 Basic Resolution 816 x 684 3x3 480 x 410 5x5 (at 2x2 combined analog and digital binning for further increase of sensitivity) Live Frame Rates: (1 ms exposure, default setting, simplified color coding) H x V Frame Rate (fps) 2464 x 2056 25 (1ms exposure time, ROI 1920 x 1080, standard color coding) H x V Frame Rate (fps) 1920 x 1080 5,5 Read Noise Full Well Capacity Dynamic Range (at gain) 2.20 e (1x) 11,000 e 1:5000 1.74 e (2x) 5,000 e 1:3100 1.48 e (4x) 2,700 e 1:1800 1.29 e (8x) 1,300 e 1:1300 1.15 e (16x) 690 e 1: 600 Software Supported Camera Operation: Exposure time adjustment with continuous, automatic or manual mode, adjustable over or under-exposure mode, optional measurement on defined target area (spot- meter) Readout of Sensor Sub Regions ("ROI"): Adjustable Digitization: 8, 12, 14 bit / pixel (8 out of 14 bit or compression mode) Dark Current: <0.5 e/p/s @ 18 °C sensor temperature Cooling: Stabilized temperature to 18 °C (for ambient temperatures from 18 °C to 30 °C) Exposure Time Range: 0.1ms to 60 s Hardware Trigger: Trigger-In for exposure time control, Trigger-Out for exposure time, readout time and trigger ready status (further accessories required) Status-LED for Camera: Color coded operation status, dimmable Camera Interface: USB 3.0 (Optional operation withUSB 2.0 at reduced frame rate) Optical Interface: C-Mount Thread Depth for Objectives: max. 5 mm Size / Weight: Approx. 10.8 cm x 7.8 cm x 5,1 cm (2.3"x 3.2" x 2,0") / 580 g Housing: blue anodized aluminum, with cooling fins on top, 1/4" photo thread for tripod mount Registration: CE Power Supply: Provided by USB 3.0 und USB 2.0, max. 7 W consumption Environmental Conditions: 5 °C to 35 °C, max. 80% relative air humidity, not condensing, free air circulation required Supported Operating Systems: for ZEN: Windows 10 x64 Supported Application Software: ZEN 3.6 (blue edition, Hotfix 3.6.6) or higher, ZEN core 3.5 (Hotfix 3.5.4) or higher The required application software is available via the ZEISS Download Center. Item no.: 426560-9071-000 Monitor TFT 24" HP Series 7 Pro 724pn (61 cm) (O) Monitor TFT 24" HP Series 7 Pro 724pn (61 cm) (O) Item no.: 410350-2408-000 Monitor TFT 24" HP Series 7 Pro 724pn (61 cm) (O) Visible diagonal: 61 cm, 16:10 Maximum resolution: 1920 x 1200 pixel @ 100 Hz Brightness: 350 nits Contrast: 1500:1 Viewing angle: horizontal 178 degree, vertical 178 degree Video input: DisplayPort1.2, HDMI 1.4 Data connectors: 4 x USB Type-A 5Gbps Power consumption: Maximum 69 W, Typical 36 W, Standby 0.5 W Dimensions incl. stand (H x W x D): 52.14 cm x 53.17 cm x 19.5 cm Weight incl. stand: 4.8 kg Ergonomic features:Tilt: -5°to +20°, Swivel:-45° to +45°, Height adjustable 15 cm, Pivot rotation: -90° to +90° Certification and compliance: CE, CB, GS, TÜV, FCC, TCO Operating voltage: 100-240 V, country-specific power cable Item no.: 410350-2408-000 Language Pack English US (O) Language Pack English US (O) Item no.: 410380-0200-000 Language Pack English US (O) - Keyboard with English (US) layout Item no.: 410380-0200-000 Memory 64 GB (2x32) DDR5-4800 (HP Z2 G9) (O) Memory 64 GB (2x32) DDR5-4800 (HP Z2 G9) (O) Item no.: 410201-6401-000 Memory 64 GB (2x32) DDR5-4800 (HP Z2 G9) (O) consisting of 2 x 32 GB modules - DDR5 4800 MHz nonECC unbuffered DIMM - can be extended to max. 128 GB (2 x 410201-6401-000) - only for 410201-9913-000 Microscopy Workstation Compact HP Z2 G9 Item no.: 410201-6401-000 Graphics Card NVIDIA RTX A4000 16 GB DP (O) Graphics Card NVIDIA RTX A4000 16 GB DP (O) Item no.: 410331-2800-000 Graphics Card NVIDIA RTX A4000 16 GB DP (O) Professional graphics card for Microscopy Workstation - 16 GB GDDR6 memory - PCI Express 4.0 Interface x16 - Hardware acceleration of DirectX 12.07, OpenGL 4.68 and CUDA - Support for up to four displays - Display outputs: 4 x DisplayPort 1.4a (DP) - DisplayPort support for 4 x 32" Display (3840 x 2160 Pixel) Item no.: 410331-2800-000 System Configuration 2 for HP Z2 G9 (O) System Configuration 2 for HP Z2 G9 (O) Item no.: 000000-2548-754 System Configuration 2 for HP Z2 G9 (O) Installation of Windows 10 IoT Enterprise LTSC 2021 x64 incl. Windows 10 License - with system integration and ZEN software installation for respective system - only for 410201-9913-000 Microscopy Workstation Compact HP Z2 G9 Item no.: 000000-2548-754 Processor Intel Core i7-12700K (HP Z2 G9) (O) Processor Intel Core i7-12700K (HP Z2 G9) (O) Item no.: 410220-0500-000 Processor Intel Core i7-12700K (HP Z2 G9) (O) High performance processor configuration - Intel Core i7-12700K (3.6 GHz 25 MB cache 12 cores (8 performance + 4 efficient) 20 threads) - only for 410201-9913-000 Microscopy Workstation Compact HP Z2 G9 Item no.: 410220-0500-000 Microscopy Workstation Compact HP Z2 G9 (O) Microscopy Workstation Compact HP Z2 G9 (O) Item no.: 410201-9913-000 Microscopy Workstation Compact HP Z2 G9 (O) - HP Z2 Tower G9 Workstation - Chipset: Intel W680 - Memory Expansion Slots: 4 x DDR5-RAM modules, 4400MHz - Memory: max. 128 GB RAM - PCI Express Connectors: 1x PCI Express Generation 5 x16 1x PCIExpress Generation 3 x4 (x16 connector) 1x PCI Express Generation 3 x4 1x PCI Express Generation 3 x1 (x4 connector) - Graphics Card onboard: Intel UHD Graphics 770 2 x Display Port 1.4 (max. 3840 x 2160 Pixel) - SSD: 1 x 512 GB M.2 NVMe - Hard disks: 1 x 8 TB SATA 7200 rpm - Network controller: 1 x GbE LAN interface (RJ 45) - USB: 4 x Type-A SuperSpeed USB 10 Gbps (front) 2 x Type-A SuperSpeed USB 10 Gbps, 1 x Type-A SuperSpeed USB 5 Gbps, 3 x Hi-Speed USB 480 Mbps (rear) - Certifications and Declarations: CE, CSA, UL, FCC, CCC, KCC - Power Supply 700W, wide-ranging with country specific plug - Chassis Dimensions: (H x W x D): 356 x 169 x 385 mm - USB Mouse - Rescue Kit Item no.: 410201-9913-000
Reflected-light illumination	Reflected-light illumination	Reflected-light illumination Reflector module bright field ACR P&C for reflected light Reflector module bright field ACR P&C for reflected light Item no.: 424928-9901-000 Reflector module bright field ACR P&C for reflected light Item no.: 424928-9901-000 Reflector module dark field ACR P&C for reflected light Reflector module dark field ACR P&C for reflected light Item no.: 424922-9901-000 Reflector module dark field ACR P&C for reflected light Item no.: 424922-9901-000	Reflected-light illumination Reflector module bright field ACR P&C for reflected light Reflector module bright field ACR P&C for reflected light Item no.: 424928-9901-000 Reflector module bright field ACR P&C for reflected light Item no.: 424928-9901-000 Reflector module dark field ACR P&C for reflected light Reflector module dark field ACR P&C for reflected light Item no.: 424922-9901-000 Reflector module dark field ACR P&C for reflected light Item no.: 424922-9901-000 Reflector module C-DIC/TIC ACR P&C for reflected light Reflector module C-DIC/TIC ACR P&C for reflected light Item no.: 424941-9000-000 Reflector module C-DIC/TIC ACR P&C for reflected light optimized for circular DIC in reflected light, for use with C-DIC/ TIC sliders 6x20, not suitable for polarization Item no.: 424941-9000-000	Reflected-light illumination Antiglare screen Antiglare screen Item no.: 452163-0000-000 Antiglare screen Item no.: 452163-0000-000	Reflected-light illumination Reflector module bright field ACR P&C for reflected light Reflector module bright field ACR P&C for reflected light Item no.: 424928-9901-000 Reflector module bright field ACR P&C for reflected light Item no.: 424928-9901-000 Reflector module polarizer ACR P&C for reflected light Reflector module polarizer ACR P&C for reflected light Item no.: 424923-9901-000 Reflector module polarizer ACR P&C for reflected light Item no.: 424923-9901-000
Reflected-light objectives	Reflected-light objectives	Reflected-light objectives Objective EC Epiplan 5x/0.13 BD M27 Objective EC Epiplan 5x/0.13 BD M27 Item no.: 422030-9961-000 Objective EC Epiplan 5x/0.13 BD M27 (FWD=11.8mm) Item no.: 422030-9961-000 Objective EC Epiplan 10x/0.25 BD M27 Objective EC Epiplan 10x/0.25 BD M27 Item no.: 422040-9961-000 Objective EC Epiplan 10x/0.25 BD M27 (FWD=11.0mm) Item no.: 422040-9961-000 Objective EC Epiplan 20x/0.4 BD M27 Objective EC Epiplan 20x/0.4 BD M27 Item no.: 422050-9961-000 Objective EC Epiplan 20x/0.4 BD M27 (FWD=3.2mm) Item no.: 422050-9961-000 Objective EC Epiplan 50x/0.75 BD M27 Objective EC Epiplan 50x/0.75 BD M27 Item no.: 422070-9961-000 Objective EC Epiplan 50x/0.75 BD M27 (FWD=1.0mm) Item no.: 422070-9961-000	Reflected-light objectives Objective EC Epiplan 10x/0.25 BD M27 Objective EC Epiplan 10x/0.25 BD M27 Item no.: 422040-9961-000 Objective EC Epiplan 10x/0.25 BD M27 (FWD=11.0mm) Item no.: 422040-9961-000 Objective EC Epiplan 20x/0.4 BD M27 Objective EC Epiplan 20x/0.4 BD M27 Item no.: 422050-9961-000 Objective EC Epiplan 20x/0.4 BD M27 (FWD=3.2mm) Item no.: 422050-9961-000 Objective EC Epiplan 50x/0.75 BD M27 Objective EC Epiplan 50x/0.75 BD M27 Item no.: 422070-9961-000 Objective EC Epiplan 50x/0.75 BD M27 (FWD=1.0mm) Item no.: 422070-9961-000 Objective EC Epiplan 5x/0.13 BD M27 Objective EC Epiplan 5x/0.13 BD M27 Item no.: 422030-9961-000 Objective EC Epiplan 5x/0.13 BD M27 (FWD=11.8mm) Item no.: 422030-9961-000	Reflected-light objectives	Reflected-light objectives Objective EC Epiplan 5x/0.13 BD M27 Objective EC Epiplan 5x/0.13 BD M27 Item no.: 422030-9961-000 Objective EC Epiplan 5x/0.13 BD M27 (FWD=11.8mm) Item no.: 422030-9961-000 Objective EC Epiplan-Neofluar 2.5x/0.06 M27 Objective EC Epiplan-Neofluar 2.5x/0.06 M27 Item no.: 422320-9900-000 Objective EC Epiplan-Neofluar 2.5x/0.06 M27 (FWD=15.1mm) Item no.: 422320-9900-000
Polarization	Polarization	Polarization	Polarization C-DIC slider 6x20 for EC EPN 5x-20x/LD EC EPN 20x-50x/EC EP 5x-100x C-DIC slider 6x20 for EC EPN 5x-20x/LD EC EPN 20x-50x/EC EP 5x-100x Item no.: 000000-1105-192 C-DIC slider 6x20 for EC EPN 5x-20x/LD EC EPN 20x-50x/EC EP 5x-100x with rotary slide-in DIC prism Item no.: 000000-1105-192	Polarization	Polarization
Lamps and Lamp housings	Lamps and Lamp housings	Lamps and Lamp housings	Lamps and Lamp housings	Lamps and Lamp housings Solid-State Light source Colibri 3, Type GB Solid-State Light source Colibri 3, Type GB Item no.: 423052-9450-000 Solid-State Light source Colibri 3, Type GB 2-channel fluorescence light source with integrated control unit in Axioscope and Axiovert 5 TL FL stand for continuous brightness adjustment, quickly switchable and adjustable by stand or - by Stand alone operation mode via OnScreenDisplay (OSD) for Axioscope with Axiocam 202/208 - by Stand alone mode via OnScreenDisplay (OSD) for Axiovert 5 TL FL SCB with Axiocam 105 R2/202/208/305/705 - software Labscope or ZEN Equipped with 2 solid state LED lamps. - Green (565nm) for excitation of Cy3, TRITC, DsRed and similar dyes - Blue (470nm) for excitation of eGFP, Fluo4, FITC and similar dyes Item no.: 423052-9450-000	Lamps and Lamp housings
Filters	Filters	Filters	Filters	Filters Filter Set 56 HE LED with Reflector Module FL EC P&C (E) Filter Set 56 HE LED with Reflector Module FL EC P&C (E) Item no.: 489056-9110-400 Filter Set 56 HE LED with Reflector Module FL EC P<(>&<)>C (E) Filter Set 56 HE LED shift free for use with ZEISS LED fluorescence light sources with excitation wavelengths 475 and 555 nm. Consisting of filters DFT 490 + 575 and DBP 512/30 + 630/98 inserted in reflector module, reflection avoided through tilted mount for emission filters. Item no.: 489056-9110-400	Filters
Measuring and counting components	Measuring and counting components	Measuring and counting components	Measuring and counting components	Measuring and counting components	Measuring and counting components Stage micrometer for reflected light 5 + 100/100y d=0mm Stage micrometer for reflected light 5 + 100/100y d=0mm Item no.: 474027-0000-000 Stage micrometer for reflected light 5 + 100/100y d=0mm - 5 lines with 1mm intervals in y-direction - 100 lines with 1/100mm intervals in y-direction Item no.: 474027-0000-000
Software for image processing	Software for image processing	Software for image processing	Software for image processing	Software for image processing	Software for image processing ZEN core 3.10 ZEN core 3.10 Item no.: 410135-0011-310 ZEN core 3.10 Software suite for microscope image acquisition, processing, analysis, and data connectivity. - Configurable graphical user interface including workbench concept for customized routine jobs and workflows - Full integration of the ZEISS microscopes (incl. Visioner 1) that can be configured in MicroToolbox, Axiocam cameras and additional components - Interactive and automatic control of the individual motorized microscope components and transfer of information from encoded components into the software - Image acquisition with b/w, rgb, high-resolution and high-sensitivity cameras - HDR, Panorama and manual Extended Depth of Focus (EDF) acquisitions - Basic image acquisition on electron microscopes - Image processing: standard operations for image optimization (contrast, brightness, gamma, colors, smoothing, sharpening, geometric corrections...) - Interactive/dimensional measurements, including online measurements on the live image - Input Form Designer with automated customer data import - Report creation and modification of Microsoft Word report templates using ZEN Word add-in - Data Archive for managing and maintaining documents: searching, filtering, tagging, viewing, re-opening, structuring, exporting, importing (any file format via drag n drop) - User Management for multi-user environment incl. full integration into the Windows multi-user functionality - Connectivity to ZEN Data Storage image database - Contains ZEN Connect basic functionality, 2D CAD overlay, topography viewer for 2.5D visualization of EDF Images incl. profile line measurement, QUAL Data Export Supported operating systems: Windows 10 (64-bit) / Windows 11 Item no.: 410135-0011-310 ZEN Toolkit Motorized Acquisition ZEN Toolkit Motorized Acquisition Item no.: 410136-0165-310 ZEN Toolkit Motorized Acquisition Acquire images and control motorized components in multi-dimensional experiments. This package allows to acquire tiles, multi-position and z-stack images using motorized components. These can be combined with the included autofocus and direct processing. z-stack and enhanced depth of focus functionality: - definition of the Z-stack in "Start/Stop" and "Center" mode - size of the configurable Z-stack and number of possible Z-planes only limited by the travel range of the system and the minimum increment - "Optimal" button to automatically set the correct increment to satisfy the Nyquist criterion - integrated Z-drive backlash compensation for maximum precision and reproducibility - extraction of the sharp details from individual images at various focus positions and combination into an image with high depth of field Tiles <(>&<)> Positions - automatic scanning of predefined sample areas - acquisition of images according to a position list - support of focus correction maps, stitching and shading correction - compatible with software autofocus Software Autofocus: - determination of the optimal focus position in the sample - the autofocus works with transmitted, reflected and fluorescence light -definition of an autofocus region in the camera image Item no.: 410136-0165-310 ZEN Module Technical Cleanliness Analysis ZEN Module Technical Cleanliness Analysis Item no.: 410136-0128-350 ZEN Module Technical Cleanliness Analysis Software module for evaluation of particulate contamination on prepared specimen. The following standards for component cleanliness, oil cleanliness, air cleanliness and cleanliness of medical products are supported: VDA 19.1, ISO 16232, ISO 4406, ISO 4407, NAS 1638, SAE AS 4059,VDA 19.2, VDI 2083 (Sheet 21). The scope of delivery includes preconfigured automated workflows for technical cleanliness analysis and rating of single or multiple specimen for the user roles Supervisor and Operator. Provided job templates (I-V): Workflow Creator Wizard for application guided selection and auto-generation of the following job templates for technical cleanliness analysis: - The workflows I - III are operable with acquired or loaded images. - The correlative workflows IV - V require image acquisition. (I) automated workflow for acquisition of multichannel images with different polarization directions in combination with Axiocam 705 pol mainly for the evaluation of component cleanliness and the rating of technical cleanliness of medical products. The use of latest camera sensor technology with on-chip polarization enables a workflow with one single specimen acquisition instead of double image acquisition of the complete specimen area with different contrast methods. This leads to a significant time saving. (II) automated workflow for acquisition of single channel images mainly for oil analysis. (III) automated workflow for component cleanliness testing with AI-based object classification. Contains trainable, pre-trained models for AI- based analysis of multichannel images with different polarization directions. Training of the delivered machine learning models requires ZEN Toolkit AI . (IV) light microscope workflow for correlative technical cleanliness analysis (component and oil cleanliness) with automated and/or manual particle selection for subsequent SEM/EDS analysis in Free Mode. Requires in addition ZEN Toolkit Connect. (V) light microscope workflow for correlative component cleanliness analysis with AI-based object classification. Contains trainable, pre- trained models for AI-based analysis of multichannel images with different polarization directions. Supports automated and/or manual particle selection for subsequent SEM/EDS analysis in Free Mode. Training of the delivered machine learning models requires ZEN Toolkit AI. Requires in addition ZEN Toolkit Connect. The job templates cover image acquisition, image analysis and image processing, result presentation in interactive views for fast inspection and revision of detected particles, reports with results of characteristic values and standard specific methods per tested specimen. Automated storage of generated results and inspection views in the data archive. Inspection and export of archived data. (VI) post analysis workflow from archived data for calculation and interpretation of results to monitor air particles using particle traps supporting VDA 19.2 The job templates cover image acquisition, image analysis and image processing, result presentation in interactive views for fast inspection and revision of detected particles, reports with results of characteristic values and standard specific methods per tested specimen. Automated storage of generated results and inspection views in the data archive. Inspection and export of archived data. Item no.: 410136-0128-350
