Carl Zeiss Microscopy, LLC - Objective Assistant - Objective "Plan-Apochromat" 63x/1.40 Oil DIC

Objective "Plan-Apochromat" 63x/1.40 Oil DIC

Item no.: 000000-1113-108
(no longer available)

Description

Objective "Plan-Apochromat" 63x/1.40 Oil DIC (WD=0.18mm)

Biomedical Applications
Magnification	63x
Numerical Aperture	1.40
Free Working Distance [mm]	0.19
Coverglass Thickness [mm]	0.17
Thread Type	W0.8x1/36"
Immersion	Oil
Field of View [mm]	25
Parfocal Length [mm]	45.06
Long Distance
Correction Ring
Iris
Optical System	Infinity Color Corrected System (ICS)
Color Correction	apochromatic
Fluorescence
- Multichannel
- Ultraviolet Transmission
- Infra Red Transmission
BrightField
DIC [Differential Interference Contrast]
High Contrast DIC
PlasDIC
Phase Contrast
VAREL Contrast
Hoffman Modulation Contrast
Polarization Contrast
Materials (Reflected Light) Applications
BrightField
BrightField/DarkField
Reflected Light DIC
High Contrast DIC
DIC with circular polarized light
Total Interference Contrast
Polarization Contrast
Options
Definite Focus.2
Confocal Microscopy
- Ultra Violet
- VIS (visible light)
- NLO-IR / 2 Photon
Total Internal Reflection Fluorescence
Apotome
Microdissection

Adapter M 27x0.75 / W 0.8 H "0"

Item no.: 000000-1095-168

Adapter M 27x0.75 / W 0.8 H "0"
Item no.: 000000-1095-168

Adapter M 27x0.75 / W 0.8 H "0"
Objective heater 22.5/34 S1 (D)

Item no.: 411860-9064-000

Objective heater 22.5/34 S1 (D)
Item no.: 411860-9064-000

Objective heater 22.5/34 S1 (D) - with oil discharge channel - clamping via front dia. 22.5 mm - max. objective dia. 34 mm - temperature range of room temperature up to +45°C
Temperable Objective Ring 22.5/32.5 mm S1 (D)

Item no.: 411882-9081-000

Temperable Objective Ring 22.5/32.5 mm S1 (D)
Item no.: 411882-9081-000

Temperable Objective Ring 22.5/32.5 mm S1 (D) clamping via front dia. 22.5 mm, max. objective dia. 32.5 mm
Immersion suction ring d=22.5 (10 pcs.)

Item no.: 444822-0000-000

Immersion suction ring d=22.5 (10 pcs.)
Item no.: 444822-0000-000

Immersion suction ring d=22.5 (10 pcs.)
Immersion oil Immersol 518 F fluorescence free, bottle 100 ml

Item no.: 444962-0000-000

Immersion oil Immersol 518 F fluorescence free, bottle 100 ml
Item no.: 444962-0000-000

Immersion oil Immersol 518 F fluorescence free, bottle 100 ml (ISO 8036-1/2, ne=1.518 (23°C), halogen-free)
Immersion oil Immersol 518 F fluorescence free, bottle 500 ml

Item no.: 444964-0000-000

Immersion oil Immersol 518 F fluorescence free, bottle 500 ml
Item no.: 444964-0000-000

Immersion oil Immersol 518 F fluorescence free, bottle 500 ml (ISO 8036-1/2, ne=1.518 (23°C), halogen-free)
Box of lens cleaning paper (300 sheets)

Item no.: 462975-0000-000

Box of lens cleaning paper (300 sheets)
Item no.: 462975-0000-000

Box of lens cleaning paper (300 sheets)

Note:

All measures in [mm]

mech. Arbeitsabstand = mechanical working distance
Deckglas = cover glass
Objektebene = object plane
Objektfeld = object field
Ausleuchtung = illumination
Probenzugänglichkeit = specimen accessibility

Note:

Please note that due to production tolerances, the given values are typical only and not guaranteed.

Plan-Apochromat

This first-class series of objectives with excellent correction and extremely high apertures provide a maximum of resolving power, color purity, contrast and image flatness for observation and photomicrography. The enormous resolving power reveals structures that otherwise can not be discerned. As image brightness in fluorescence microscopy increases with the power of four of numerical aperture, Plan Apochromat objectives are excellently suited to fluorescence applications.

Objective "Plan-Apochromat" 63x/1.40 Oil DIC (WD=0.18mm)
