Objective A-Plan 40x/0.65 M27
Objective A-Plan 40x/0.65 M27
Item no.: 421060-9900-000Objective A-Plan 40x/0.65 M27 (FWD=0.45mm)
Full DescriptionMagnification | 40x |
Numerical Aperture | 0.65 |
Free Working Distance [mm] | 0.45 |
Coverglass Thickness [mm] | 0.17 |
Thread Type | M27x0.75 |
Immersion | Without Immersion |
Field of View [mm] | 23 |
Parfocal Length [mm] | 45.06 |
Long Distance | |
Correction Ring | |
Iris | |
Optical System | Infinity Color Corrected System (ICS) |
Color Correction | achromatic |
Biomedical Applications | |
---|---|
Fluorescence | |
- Multichannel | |
- Ultraviolet Transmission | |
- Infra Red Transmission | |
BrightField | |
DIC [Differential Interference Contrast] | |
High Contrast DIC | |
PlasDIC | |
Phase Contrast | |
VAREL Contrast | |
Hoffman Modulation Contrast | |
Polarization Contrast | |
Materials (Reflected Light) Applications | |
BrightField | |
BrightField/DarkField | |
Reflected Light DIC | |
High Contrast DIC | |
DIC with circular polarized light | |
Total Interference Contrast | |
Polarization Contrast | |
Options | |
Definite Focus.2 | |
Confocal Microscopy | |
- Ultra Violet | |
- VIS (visible light) | |
- NLO-IR / 2 Photon | |
Total Internal Reflection Fluorescence | |
Apotome | |
Microdissection |
-
Objective ring ACR for objective sleeve cylindrical short
Item no.: 424508-0000-000Objective ring ACR for objective sleeve cylindrical short
Item no.: 424508-0000-000Objective ring ACR for objective sleeve cylindrical short
-
Adapter 30mm with optics and DIC slider mount
Item no.: 424516-9041-000Adapter 30mm with optics and DIC slider mount
Item no.: 424516-9041-000Adapter 30mm with optics and DIC slider mount for adaptation of objectives M27 with parfocal length of 45mm
-
Slider PlasDIC for A-Plan 40x/0.65
Item no.: 426980-9030-000Slider PlasDIC for A-Plan 40x/0.65
Item no.: 426980-9030-000Slider PlasDIC for A-Plan 40x/0.65
Note:
All measures in [mm]
mech. Arbeitsabstand = mechanical working distance
Deckglas = cover glass
Objektebene = object plane
Objektfeld = object field
Ausleuchtung = illumination
Probenzugänglichkeit = specimen accessibility
Note:
Please note that due to production tolerances, the given values are typical only and not guaranteed.
This class of objectives provides an attractive alternative to Achroplan objectives, both in routine and research applications. A-Plan objectives provide rich contrast and can be used with eyepieces with a field of view up to 23 mm.They allow contrasting methods ranging from brightfield to phase contrast and for excitation wavelength within the visible spectrum they can be used for epifluorescence work.
Objective A-Plan 40x/0.65 M27 (FWD=0.45mm)
